Collet holder ER
-
Norm: DIN ISO 15488 -
Typ: ER -
Form: B
DIN ISO 15488 • for application without sealing washer • concentricity < 6 µm • for high-performance tools with internal cooling e.g. HR 500 reamers • clamping force tester for SK/BT/CAT clamping systems in machine tool spindles • metallic sealing up to coolant pressure of 300 bar • ER-DM collets with restricted clamping range • The tool must be clamped at least flush or deeper in the collet. A minimum clamping length of 2/3, as for standard collets, is not possible otherwise there would be no seal.
SKU
4175
ISO code
| P | Steel, high-alloyed steel |
|---|---|
| M | Stainless steel |
| K | Grey cast iron, spher, graphite/mall. cast iron |
| N | Aluminium and other non-ferrous metals |
| S | Special, super and titanium alloys |
| H | Hardened steel and chilled cast iron |
On the following programme pages you will find for every tool recommendations regarding suitability for the application groups and details of max. tensile strength and harness:
optimal suitability
limited suitability
optimal suitability
limited suitability
Available in many variants
